RV-R2PRO44

RV-R2PRO44 is used for conference, lecture hall.

Product Series:

WIRELESS CONFERENCE


Main Features:

RV-R2PRO44

426x185x50 mm

black

±5PPM(-5~50℃)

5dBm (max)

60HZ-18000HZ


SPECIFICATIONS


APPLICATION USES

RV-R2PRO44 is used for conference, lecture hall.

FEATURES

1. One-to-four conference microphone.

2. The receiver has built-in narrowband technology and ID coding technolo-gy, and can be used with up to 28 microphones.

3. True diversity, with an unobstructed receiving distance of 80 meters.

4. Handheld, collar clip, headband, and conference can be mixed andmatched for use.



SPECIFICATIONS



Product(Host)

RV-R4

DC Power Supply

2A 12V

Channel Groups

4 channels

Panel Display

LCD screen

Frequency Stability

+5ppm(-5~50℃)

Carrier Frequency Band

UHF:640.125MHZ-690.000MHz;805.125MHz-823.750MHZ

Frequency Interval

600MHz:50(6.25*4*2)MHz; 800MHz: 25(6.25*4*1)MHz

Effective Working Distance

125KHz

Switchable frequencies

600MHz:400(50x4x2);800MHz: 200(50x4x1)

Receiving Mode

True Diversity

Sensitivity

-105dBm(12dB S/N)

Maximum Deviation

±45KHz

Signal-To-Noise Ratio

>75dB(1KHz-A)

Comprehensive Distortion

≤0.5%@1KHz(12dB S/N)

Comprehensive FrequencyResponse

60HZ-18000HZ

Output Socket

XLR balanced socket independent output and Ф6.3 unbalanced socket mixed output

Receiving Distance

Barier-free receiving distance of about 80 meters

Dimensions

426x185x50 mm



RECEIVER INDICATORS



Product(Microphone)

RV-T6BL

Power Supply

2 AA batteries

Oscillation Mode

PLL phase-locked frequency synthesisPLL phase-locked frequency synthesis

Carrier Frequency Band

UHF:640.125MHZ-690.000MHz:805.125MHZ-830.000MHZ

Bandwidth

600MHz:50(6.25*4*2)MHZ;800MHz:25(6.25*4*1)MHZ

Frequency Interval

125KHz

Switchable Frequencies

600MHz:400(50x4x2);800MHz:200(50x4x1)

FM Mode

Infrared frequency matching

Radiated Power

5dBm (max)

RF Stability

±5PPM(-5~50℃)

Maximum Deviation

+45KHz

Pickup Head

Capacitive

Battery Life

About 8 hours

DIMENSIONS
